Poslab PL-260N 3" Thermal Receipt Printer

Features and Specs

WHAT'S IN THE BOX?

Poslab 3" Thermal Receipt Printer (PL-260N)

Specs:

• Model: PL-260N
• Printing method: Direct Thermal
• Printing speed: 260mm/s
• Paper width: 79.5 + 0.5mm
• Printable area: 72mm (adjustable by commands)
• Maximum paper diameter: 80mm
• Paper Thickness: 0.06-0.08mm
• Column capacity: 576 dots/lines 512 dots/lines
• Line space 3.75 mm (Changeable by commands)
• Commands: Compatible with ESC/POS
• Interface type: USB+Serial+Lan
• Character size
• ANK, Font A: 12 x 24 DOTS
• Font B: 9 x 17 dots
• Simplified/ traditional Chinese: 24 x 24 dots
• Dimensions: 185.7 x 140 x 134 mm (D x W x H)
• Gross weight: 1.025 kg
• Bar code:UPC-A/UPC-E/JA (EAN13)/ JAN8 (EAN8)/ CODE39/ITF/CODABAR/CODE93/CODE128
• 2-dimension code:QR CODE / PDF417
• Code page: PC347 (Standard Europe), Katakana, PC850 (Multilingual), PC860 (Portuguese), PC863 (Canadian-French), PC865 (Nordic), West Europe Greek, Hebrew, East Europe, Iran, WPC1252, PC866(Cyrillic#2), PC852 (Latin2), Pc858, Iranll, Latvian, Arabic, PT151 (1251)
• Cutter: Partial
• Cutter life: 1.5 million cuts
• Print head life: 100KM
• Input buffer: 64 Kbytes
• NV Flash: 256 Kbytes
• Power adaptor: AC110V/220V, 50-60Hz
• Power source:DC 24V/2.5A
• Cash drawer output: DC 24V/1A
• Work environment: Temperature: 0-45 C, humidity: 10-80RH%
• Storage environment: Temperature: 10-60 C, humidity: 10-90RH%
• Operating system: Win XP/ Win Vista/ Win 7/ Win 8/ Win 8.1/ Win 10/ Linux
